ART Longrange 3D

360º fast-scan C-UAS radar

ART Longrange 3D image

ART Longrange 3D is part of the fourth generation of ART award-winning high-resolution C-UAS surveillance radar family. This high-performance sensor is specifically tailored to address the requirements of the Security & Defense market and Air Traffic Regulation institutions in two key applications: counter small unmanned aerial vehicle systems (C-UAS) and unmanned aircraft traffic management (UTM). Featuring a 3D multi-beam antenna system, the radar detects, tracks and classifies micro quadcopters and micro fixed-wing UAS with extended elevation coverage.


ART Longrange 3D can be complemented with electro-optical platforms, soft kill/hard kill countermeasure devices and ART HMI Multi-sensor Command and Control Software, to obtain an industry leading integrated solution. The combination of these elements provides complete situational awareness in complex real-life environments.

product image

Coverage

Complete 360º coverage with a single unit.

product image

Update Rate

Fast scan rate in all operational modes providing early target confirmation.

product image

Detection Performance

State-of-the-art detection range for UAVs, personnel and light vehicles. Detectable target RCS below 0,01 m².

product image

Technology

Multi-beam antenna that provides a direct measurement of the target altitude.

Highlights

Build a high-performance early warning solution

Build a high-performance early warning solution

Designed for high-performance early warning, this 3D long-range counter-drone radar delivers extended detection ranges, ensuring reliable defense against military-grade threats.

Integration-ready for comprehensive security

Integration-ready for comprehensive security

ART Longrange 3D seamlessly integrates with electro-optical platforms and both soft and hard kill countermeasures using standard protocols like SAPIENT and ASTERIX. This guarantees interoperability within multi-sensor solutions, enhancing critical infrastructure protection and adapting to evolving C-UAS missions.

Leverage a decade of proven expertise

Leverage a decade of proven expertise

Backed by more than a decade of proven expertise, ART Longrange benefits from a globally deployed family of radar systems, sharing robust subsystems and extensively field-proven components.

Applications

ART Longrange 3D

Waveform

Wideband coherent Doppler CWLFM Low Probability of Interception (LPI)

Frequency band

X band

Transmitter type

Solid state GaN

RF transmission masking

Configurable RF transmission azimuth sectors

Processing

Multi-beam processing for 3D target detection Coherent integration - Doppler processing Adaptive clutter map Track-before-declare Multi-mission multi-target tracker

Scan speed

60 or 30 RPM

Instrumental detection range

40, 20 or 10 km

Technologies

  • Single unit with 360° coverage and fast scan rate

  • Direct measurement of target altitude

  • Small target detection better than 0.01 m² RCS

  • Low operation workload, automatic adaptation to the environment

  • High range accuracy and resolution

  • Target classification

  • Interoperability with additional devices (electro-optical, jammer…)

ART R&D Team has a broad scope of research and engineering background that results in an extensive range of cutting edge capabilities.
